ATE-BPTOC014 BASIC PLCTRAINER OMRON CP1E
PRODUCT DESCRIPTION :
ATE-BPTOC014 introducing the student to the basicoperation, programming and troubleshooting of industrial programmable logic controllers. A curriculum is provided incorporating many learning activities related to basic sequence, circuit flow, ladder logic programming and trouble shooting. Many activities reflect realistic industrial applications.
PRODUCT FEATURE :
•Works with Existing Equipment
•Equipped with manual switches to simulate all inputs
•Equipped with indication lights to simulate all outputs
•Open system. Ready to communicate with personal PC
•Easily and Portable
•Shortage-circuit protection
•Allows for attachment to external devices.
•Easy connect ability to existing motor sensors, valves and switches through standard banana jacks
PLC MAIN UNIT
ITEM DESCRIPTION UNITS
Controller (CPU) Micro PLC 1 ea
Input 24V DC Input 12 ea
Output Relay Contact Output 8 ea
Cable Program download cable 1 ea
Power Supply 24 V DC 2.1 A (short circuit protection) 1 ea
Input Terminals 4mm Ø Banana Jack 12 ea
Output terminals 4mm Ø Banana Jack 8 ea
Input Switches Toggle Switch 12 ea
Simulation Indicators LED 20 ea
Relay 8 pin (with base Relay) DC 24V 1 ea
EXPERIMENT TOPICS :
•Fundamentals of Logic
•Programming Language
•Developing Ladder Logic Programs
•Programming timers
•Structure of Control Systems
•Sequencer Programs
•Master Control & Zone Control Instructions
•Programming Counters
•Jump Instructions and Sub-routines
•Combined Counter and Timer Functions
•PLC Installation Practices
